English: A selection of NEMA receptacles, showing ground, neutral, and hot/line pins. Earth/ground is dark green, neutral is white, and hot/line is black.
Typical modern North American uses for common receptacles are shown in purple. Sadly, this is not an exhaustive list. References: Receptacle side shown here: http://www.nooutage.com/nema_configurations.htm Plug side shown here: http://www.refurbups.com/Plug-Information Prints smaller than actual size. Plugs drawn freehand; mechanical dimensions are very approximate. Electrical connections should be positively verified before use, as this information was collected from online sources of unknown reliability. |
⧼wm-license-information-date⧽ | 2011 |
⧼wm-license-information-source⧽ | ⧼Wm-license-own-work⧽ |
⧼wm-license-information-author⧽ | قالب:Ut |
⧼wm-license-information-other-versions⧽ |
This version simplified from my table:NEMA receptacle pins.svg قالب:F by removing the bottom row's 3-phase power plugs and IEC computer connectors, as a way to simplify the table.
